Parker domnick hunter LCMS15 Series User Manual

3
2 Description
The LCMS generators provide a continuous stream of high purity nitrogen from a single ‘plug & play’ unit. Models are available with and without
an integral oil free compressor, are extremely quiet in operation and are fully approved for use by major instrumentation manufacturers.
2.1 Technical Specification
This specification is valid when the equipment is located, installed, operated, and maintained as specified within this user guide.
Units LCMS15-0 LCMS15-1 LCMS20-0 LCMS20-1 LCMS30-0 LCMS30-1 LCMS40-0 LCMS50-0
Drying, Sheath and Nebulisation Gas
Flow L/min 15 20 30 40 50
Outlet Pressure
bar g
(psi g)
7
(101.5)
Purity (with respect to O
2
)
% >99.5 >99 >98 >99 >98
Inlet Parameters
Integral Compressor - N/A Yes N/A Yes N/A Yes N/A
Inlet Air Quality
ISO 8573-1: 2010
1.-.1 N/A 1.-.1 N/A 1.-.1 N/A 1.-.1
Inlet Air Pressure
bar g
(psi g)
8.5
(123.3)
N/A
8.5
(123.3)
N/A
8.5
(123.3)
N/A
8.5
(123.3)
Maximum Inlet Air
Temperature
o
C
(
o
F)
35
(95)
N/A
35
(95)
N/A
35
(95)
N/A
35
(95)
Flow (@ 8.5 bar g) L/min 70 N/A 70 N/A 130 N/A 130
Port Connections
Air Inlet
1
1. Compression fitting
- 1/4 N/A 1/4 N/A 1/4 N/A 1/4
Gas Outlet
1
-
1/4
2
2. Using the 1/8 - 1/4 adaptor provided.
Electrical Data
Supply Voltage Vac 230 ± 10% 50Hz
Connection type - IEC320
Current
3
3. The power consumption when in standby mode is 35W for all models.
A 0.8 5.8 0.8 5.8 0.8 5.8 0.8
Fuse A
2.0
3
6.3
4
2.0
3
6.3
4
2.0
3
6.3
4
2.0
3
Supply Voltage Vac 120 ± 10% 60Hz
Connection type - IEC320
Current
3
A 1.6 11.6 1.6 11.6 1.6 11.6 1.6
Fuse A
2.0
4
4. (Anti surge (T), 250V, 5 x 20mm HBC, Breaking Capacity 1500A @250V, IEC 60127, UL R/C)
12.5
5
5. (Anti surge (T), 250V, 6.3 x 32mm HBC, Breaking Capacity 1500A @440V, IEC 60127, UL R/C)
2.0
3
12.5
4
2.0
3
12.0
4
2.0
3
Environmental Data
Ambient Temperature
o
C
(
o
F)
5–40
(41–104)
Relative Humidity
50% @ 40
o
C (80% MAX < 31
o
C)
IP Rating IP20, NEMA 1, indoor use only
Pollution Degree 2
Installation Over voltage
Category
II
Maximum Altitude
m
(ft.)
2000
(6562)
Noise dB(A) < 65
