PGP/PGM 300 Series
Gear Pumps & Motors Service Manual
Catalog HY13-PMD300-SM/US
Bill of Materials
ITEM DESCRIPTION
1 Snap Ring
2 Outboard Bearing
3 Lip Seal, Shaft Seal
4 Shaft End Cover, Flange
5 Bushing
6 Backup Seal
7 Channel Seal
8 Thrust or Pressure Plate
9 Gear Shaft, Drive Gear
10 Driven Gear, Idler Gear
11 Square Seal, Section Seal
12 Dowel Pin
13 Gear Housing, Body
14 Bearing Carrier
15 Connecting Shaft
16 Drive Gear
17 Port End Cover, Rear Cover
18 Stud, Cap Screw, Fastener
19 Washer
20 Hex Nut
