PVSG User Guide
2
e dierent models of the PVSG and their features are listed in the following tables:
Basic
Characteristic Number Description
CAN bus ports 5 Supports CAN 2.0 for e.g. J1939, CANopen
WiFi 0 802.11 b,g,n
External antenna conn. 0 Antenna may be connected for additional range
Ethernet 0 100base Tx for wired PC connection
USB 1 USB Host/Device (OTG)
J1708 1 Legacy heavy-duty vehicle (truck and bus) protocol
LIN 0 For communication with automotive components
Data logging memory 0 Memory for logging events, CAN messages etc.
RTC 1 Real time clock
Inputs 2 Active-high GPIO with wake up capability
Outputs 1 High-side
Advanced
Characteristic Number Description
CAN bus ports 5 Supports CAN 2.0 for e.g. J1939, CANopen
WiFi 1 802.11 b,g,n
External antenna conn. 1 Antenna may be connected for additional range
Ethernet 1 100base Tx for wired PC connection
USB 1 USB Host/Device (OTG)
J1708 1 Legacy heavy-duty vehicle (truck and bus) protocol
LIN 4 For communication with automotive components
Data logging memory 4 GB Memory for logging events, CAN messages etc.
RTC 1 Real time clock
Inputs 2 Active-high GPIO with wake up capability
Outputs 1 High-side
