Parker SciLog DINCon User Manual

21
114 R/W 16 bit TCP Mask P1
255
115 TCP Mask P2
255
116 TCP Mask P3
255
117 TCP Mask P4
0
118 R/W 16 bit TCP Gateway P1
192
119 TCP Gateway P2
168
120 TCP Gateway P3
0
121 TCP Gateway P4
1
130 R/W 16 bit RTCC Control
bit0: Set Clock Values
Registers 130-137 must be written as a block
131 R/W 16 bit Day of Week (1-7)
132 R/W 16 bit Month
133 R/W 16 bit Day
134 R/W 16 bit Year
135 R/W 16 bit Hour (24)
136 R/W 16 bit Minute
137 R/W 16 bit Second
140 R/W 16 bit Pressure Units
0
0 = psi
1 = kPa
2 = bar
3 = mmHg
141-142 R/W IEEE Float
Cal Pressure (Default 30psi)
(Only change for use with a Custom Calibration)
30.0
143 R/W 16 bit Data Refresh Rate
0
0 = 13 milliseconds
1 = 25 ms
2 = 50 ms
3 = 125 ms
4 = 250 ms
5 = 350 ms
6 = 500 ms
7 = 750 ms
8 = 1 second
9 = 1.5 seconds
10 = 2 seconds
11 = 4 seconds
150 R 16 bit P1 Status
bit 0 = Disconnected
bit 1 = Uncalibrated
bit 2 = Low Alarm
