Parker SciLog DINCon User Manual

22
bit 3 = High Alarm
151-152 R IEEE Float P1 Pressure Value
153 R 16 bit P2 Status
bit 0 = Disconnected
bit 1 = Uncalibrated
bit 2 = Low Alarm
bit 3 = High Alarm
154-155 R IEEE Float P2 Pressure Value
156 R 16 bit P3 Status
bit 0 = Disconnected
bit 1 = Uncalibrated
bit 2 = Low Alarm
bit 3 = High Alarm
157-158 R IEEE Float P3 Pressure Value
160-161 R/W IEEE Float P1 Pressure Alarm Limit - Low
0.0
162-163 R/W IEEE Float P1 Pressure Alarm Limit - High
0.0
164-165 R/W IEEE Float P2 Pressure Alarm Limit - Low
0.0
166-167 R/W IEEE Float P2 Pressure Alarm Limit - High
0.0
168-169 R/W IEEE Float P3 Pressure Alarm Limit - Low
0.0
170-171 R/W IEEE Float P3 Pressure Alarm Limit - High
0.0
201 R/W 16 bit P1 Sensor ID Type
0 = Luer
1 = 3/8" Barb
2 = 1/2" Barb
3 = 3/4" TC
4 = 1" TC
100 = Cal Fixture
202 R/W 16 bit P1 Sensor ID Material
0 = Polypropylene
1 = Polysulfone
203 R/W 16 bit P1 Sensor ID Month
204 R/W 16 bit P1 Sensor ID Year
205 R/W 16 bit P1 Sensor ID Lot
206 R/W 16 bit P1 Sensor ID Unit Number
208 R/W IEEE Float P1 Sensor Pressure Offset (PZ)
210 R/W IEEE Float P1 Sensor Cal Factor (CF)
212 R/W IEEE Float P1 Sensor Cal Pressure (CP1)
214 R/W IEEE Float P1 Sensor Cal Factor 2 (CF2)
216 R/W IEEE Float P1 Sensor Cal Pressure 2 (CP2)
220 R/W 16 bit P1 Sensor Custom Cal Status
bit 0 = Invalid
bit 1 = Start Zero
