Hardware
Specifications – All Modules
Dimensions
W: 0.875¨ (2.2 cm); Height 4.0¨ (10.2 cm); D: 4.75¨ (12.1 cm)
Weight
0.3 lb. (0.14 Kg)
Enclosure
Molded Plastic
Electrical
Power
24 VDC, 250 mA. Use only Class 2 External Power Supply
Battery
CR1632, used for internal clock, not user serviceable
I/O Port Top
8 pin Terminal Block, numbered from rear:
1: +24 VDC 2: 24 VDC Return 3: N/C 4: Signal GND (COM)
5: RS-232 RX 6: RS-232 TX 7: RS-485 A 8: RS-485 B
I/O Port – 2
RJ45, Ethernet Connection
I/O Port - 3
USB Connection
Software
I/O Port
Bottom
8 Pin Sensor Connection, DINCon has 1, DINPres and
DINTemp have 3.
DISPLAY
Power Status LED, Sensor Status LED’s
Modbus
Modbus RTU via RS-232
Modbus RTU via RS-485
Modbus RTU via USB
Modbus TCP via Ethernet
Environmental
Temperature
4 – 60° C
Altitude
Up to 2000 Meters
IP Rating
IP20, Indoor dry environments, unit is wipe-down only
Rel. Humidity
0 – 95%
Voltage
Fluctuation allowed: +/- 10%
Pollution
Degree: 2
