1 Introduction
The ServiceJunior is a digital manometer featuring a MIN/MAX display function.
Full scale (FS) accuracy is ± 0.5% based on the upper limit of the measurement range.
Dynamic pressure peaks are measured at a scanning rate of 10 ms (100 measurement
values/second). The MIN/Max memory is continuously updated and rewritten.
1.1 Notes on safety/production selection
The correct functioning of the ServiceJunior can only be guaranteed when the specifications detailed
in these operation instructions are adhered to.
In particular, specifications relating to the permitted upper limit of the measurement range as well as
the permissible temperature range must be observed.
For repairs or calibration of the measurement instruments, please contact a
Parker sales branch.
1.2 Device versions and range of delivery
Device versions/ Range of delivery
Basic setting to unit “bar”
Pressure port ½“ BSPP (pressure gauge)
Delivery includes rubber protection
2 x batteries 1,5 VDC (Mignon)
Range
-1.000…+1.000 mbar -1,00…+4,00 bar 0…60,0 bar 0…400,0 bar
Serious malfunctions leading to personal injury or damage to property can result from
using the chosen product in applications that do not comply with the specifications
or from disregarding the operating instructions.
In particular, incorrect mounting of the manometer and the corresponding adapter can
cause the manometer to be torn.
