3.1 Display Mode
The actual pressure (ACT) is indicated in the display mode. The ACT measured value is displayed in
the corresponding unit. The MIN, MAX or FS values is indicated in the lower part of the display.
Display Description
bar-graph
Graphic indication of the actual pressure.
A pressure peak is indicated by means of a pixel (graduation mark).
The indicated value is refreshed at intervals of
50 ms (20 measurements/sec).
ACT
Indicates the actual pressure.
The indicated value is refreshed at intervals of 300 ms (3 times/sec).
MIN/MAX
Indicates the MIN, MAX or FS value according to setting.
The indicated value is refreshed at intervals of 300 ms (3 times/sec).
FS
Upper limit of the scale (e.g. 400 bar)
Units
Indicates the chosen unit
Battery
Indicates battery status (5 segments)
x10
Indicated value (actual indication and MIN/MAX indication) x10.
