104 VIX AE SERVO DRIVE USER GUIDE
Drive Faults
Bit Number Stop Type DF Information
1 Composite fault (anything that causes a drive
fault)
2 K T +/-15V supply rail
3 K R Motor HV under-voltage trip point reached
4 K R Motor HV over-voltage trip point reached
5 C R V I/O under-voltage trip point reached
6 C R V I/O over-voltage trip point reached
7 K T Encoder/Auxiliary 5V under voltage trip
8 K T Impending power loss
(24V – logic supply)
9 K T Commutation Fault
10 K T Resolver fault
11 C R Motor over temperature
12 C R Ambient over temperature
13 C R Drive over temperature
14 K T Incompatible firmware version
15 K T Unrecognised power stage
16 K T Controller diagnostic failure
17 K R Output stage over current
18 C R Output driver over current
19 C R Tracking limit exceeded while in motion is a
latched fault
20 K R Velocity exceeded (unstable gains/motor spin-
off)
21 C R Energise input not set – check energise input
and state of ES variable
22-24 Reserved
25 K T Watchdog 1
26 K T Watchdog 2
27 K T Watchdog 3
Key: C: Performs controlled stop
K: Performs motion kill – quick stop. Possible instant de-energise depending on fault source
R: Recoverable without power cycle
T: Terminal (requires power cycle or repair before drive will energise/operate again)
