2 VIX AE SERVO DRIVE USER GUIDE
Product Variants
Digital servo drives are available in two power versions, with resolver or encoder feedback.
Table 1-1 lists the possible combinations:
Product Code Description
ViX250AE 250VA Servo with encoder/resolver feedback
ViX500AE 500VA Servo with encoder/resolver feedback
Table 1-1. ViX250/ViX500 Digital Servo Drive Options
Product Features
Protection Circuits
Motor short circuits
Over-voltage
Under-voltage
Drive/motor Over-temperature
24V reverse supply protection
Commutation encoder fault
Resolver fault
I
2
t protection
Function Indicators
Drive Status/Feedback Fault (HV/FB)
Drive Fault (DF)
Outputs and Inputs
1 Brake input
1 Brake output
1 Analogue monitor output
