Parker ViX500AE - Drive Dimensions

6 VIX AE SERVO DRIVE USER GUIDE
Drive Dimensions
ViX250 and ViX500 drives share the same dimensions, shown in Figure 2-1.
4,5
98.5 (with connector)
21
4,5
88,1
42
3
10.1
124.7
135
145
5
X1
X3
X4
X5
X2
HVSTFB
Figure 2-1. ViX250 & ViX500 Dimensions
