20 VIX AE SERVO DRIVE USER GUIDE
SMB Motor Cables
The following motor power and feedback cables are available for ViX drives:
Power cable Feedback cable
VIX-PWR-XXXX VIX-FDB-XXXX
Table 3-3. Motor Power and Feedback Cables
Where XXXX is the length of the cable in cm, up to a maximum length of 20 metres in 2.5
metre increments. In the case of SMB motor cables the feedback cable can be used for
resolver or encoder feedback.
BE & SM Motor Cables
When using BE- or SM-Series motors choose the appropriate connector option to ensure the
temperature sensor output is made available on the required connector:
• BE- nMSn
• SM- nGSn
Motor power cables are identified using the number 71-021125-XX, where XX is the length
of the cable in feet, up to a maximum of 50ft (15.24m) in 5ft (1.524m) increments.
The form of feedback cable used with both the BE- and SM- range will depend upon the type
of feedback transducer:
• Resolver feedback 71-021123-XX
• Encoder feedback 71-021124-XX
Once again XX defines the length in ft.
Should you require a BE or SM servo motor with a mechanical brake, please contact
Parker. See the front of this user guide for contact details.
