Parker ViX500AE - Page 54

3. ELECTRICAL INSTALLATION 47
FEM1 CAT5 cable colours
X6 CANopen/RS485
1 RX+/TX+ RS485 White/Orange
2 RX-/TX- RS485 Orange
3 Reserved White/Green
4 RS232 Gnd Blue
5 RS232 Gnd White/Blue
6 Reserved Green
7 RS232 Tx White/Brown
8 Rs232 Rx Brown
X7
1 RX+/TX+ RS485 White/Orange
2 RX-/TX- RS485 Orange
3 Reserved White/Green
4 RS232 sense Blue
5 RS232 Gnd White/Blue
6 Reserved Green
7 RS232 Rx White/Brown
8 RS232 Tx Brown
Table 3-14. X6/X7 Input/Output Connections
