Parkside PBCG B2 - Parts Description; Display Indicators

GB 13
Parts description (Fig. A)
1
Adapter ‒ 33.3 mm to 26.5 mm
(G 1
to G ¾ )
2
Filter
3
Union nut – 33.3 mm (G1 )
4
Button
5
Button
6
Rotary control
7
Battery compartment screw
8
Battery compartment
9
Adapter (for coupling the hose)
10
Display
Display indicators (Fig. B)
11
Battery status
12
Current time
13
Current weekday
14
Program start time
15
Run time – watering duration
16
Irrigation start indicator
17
Programmed watering days
18
Current watering program (1–6)
19
ON
20
Irrigation
21
Pause
22
OFF
