22 GB
ATTENTION! The irrigation controller may only be connected to a drinking
water abstraction point with a safety device which corresponds to TYPE HD at
the very least according to EN 1717 (backflow preventer with tube ventilation).
Note: Such mains adapters are available from speciality retailers.
Check the water connection type available. The product is fitted with a union
nut
3
for a tap with a 33.3 mm thread (G 1 ). For a tap with a 26.5 mm thread
(G ¾ ) use the adapter
1
supplied.
Insert the filter
2
into the union nut
3
as depicted in Figure A.
F
or a 26.5 mm thread (G ¾ ): Screw the adapter
1
onto the tap. Do not us
e
any tools for this purpose.
S
crew the union nut
3
onto the thread of the tap or the adapter. Do not use
any tools for this purpose.
Screw the adapter
9
onto the hose connection. You can then connect a
hose to the adapter
9
.
Open the tap.
AT
TENTION! If defects/leaks arise when using the adapter
1
, the thread
of the tap must be wrapped using sealing tape.
Programme irrigation as described in the chapter “Operation”.
