Parkside PPS 40 A1 Operation And Safety Notes Translation Of The Original Instructions

8 GB/CY
1
Plasma cutter
2
Handle
3
Mains plug
4
Ground terminal
5
Ground terminal plug
6
Plasma burner - power plug
7
Plasma burner - plug
8
Plasma burner
8a
Plasma burner button
8b
Nozzle clamping sleeve
8c
Nozzles
8d
Electrode
8e
Diffuser
9
Overheat protection indicator lamp
10
Plasma burner - power socket
11
Ground terminal - connection socket
12
Plasma burner - connection socket
13
Current controller
14
Mains indicator lamp
15
Quick connector compressed air hose
16
Compressed air hose
17
On/off - switch
I switched on
O switched off
18
Condensation water tank
19
Manometer
20
Compressed air connection
21
Rotary knob to regulate the pressure
22
Hose clamp
• Technical specifications
Output: 15 - 40 A
Input: 230 V~ 50 Hz
Weight: approx. 5.2 kg
Dimensions 341 × 113 x 237 mm
Insulation class: H
Duty Cycle: 35 % at 40 A (25 °C)
20 % at 40 A (40 °C)
‘Real’ cutting
capacity: 0.1 mm – 12 mm
(depending on the material)
Copper:1 - 4 mm
Stainless steel: 1 - 8 mm
Aluminium:1 - 8 mm
Iron: 1 - 10 mm
Steel: 1 - 12 mm
Working
pressure: 4 - 4.5 bar
(4 bar preset)
• Package contents
1 plasma cutter
1 ground cable with terminal
1 cutting cable incl. cutting torch
1 compressed air hose with Quick-Connect
2 hose clamps
2 nozzles
3 electrodes (1 pre-assembled)
1 set of operating instructions
3 burner sleeves (1 pre-assembled)
• Safety instructions
WARNING!
f Please read through the
operating instructions
carefully before use.
Familiarise yourself with the
device, its proper use and
the safety notes based on
these operating instructions.
These form part of the
product and must be
available at all times.
Introduction / Safety instructions
