PARKZONE Archer - Center of Gravity (CG)

EN
The CG location is 40mm back from the leading edge of the wing. Install the
fl ight battery all the way to the front of the battery compartment. Make sure
the fl ight battery is secured using the hook and loop strap. It is easiest to bal-
ance the Archer with the aircraft inverted.
Center of Gravity (CG)
40mm
1.60 inches
back from the
leading edge of
the wing.
Installing the Landing Gear
1. Turn the fuselage so that the bottom of the wing faces up.
2. Install the main landing gear by inserting the main gear struts (A) into the
corresponding gear plate hole located on each wing.
3. Carefully turn each strut in the gear plate until the horizontal section of the
strut snaps into place.
When needed, disassemble in reverse order.
A
11
