Move the controls on the transmitter to make sure the aircraft control surfaces move correctly and in the proper direction. After performing the Control Test,
correctly set the failsafe. Make sure the transmitter controls are at neutral and the throttle and throttle trim are in the low position, then rebind the model to your
transmitter. If the receiver loses its link to the transmitter, the failsafe will drive the servos to these settings made at binding.
Control Direction Test
Transmitter Command Aircraft Reaction
Elevator
Up Elevator Command
Down Elevator Command
Aileron
Stick Right
Stick Left
Rudder
Stick Right
Stick Left
Dual Rates
Your DSM2/DSMX full range transmitter features dual rates to help you select
the amount of travel that you want from the control surfaces.
High Rate Low Rate
Aileron 12mm up/down 9mm up/down
Elevator 9mm up/down 7mm up/down
Rudder 12mm left/right 8mm left/right
