3
WARNING：
The fuel tank supplied with this engine could only be used as supply of fuel for its running and must
not be as a fuel storage container.
The fuel cock must be at close position while using portable fuel tank.
Disconnect the fuel joint while using the built-in fuel tank.
1.2 General information
1.2.1 Specifications
Main technical data:
Items Data Items Data
Type of engine 4-stroke S Weight (L) 28Kg
Displacement 148cm
3
Recommended fuel Unleaded regular gasoline
Bore X stroke 64mm×46mm Built-in fuel tank capacity 1.3L
Gear ratio 2.08（27/13） Recommended engine oil SAE10W30 orSAE10W40
Overall length 718mm Engine oil quantity 0.6L
Overall width 390mm Recommended gear oil Hypoid gear oil SAE﹟90
Overall height (S) 1050mm Gear oil quantity 100cm
3
Overall height (L) 1177mm Spark plug CR6HSA
Weight (S/L) 27Kg/28Kg Spark plug gap 0.6～0.7mm
