38
3. Remove gear oil drain screw.
1. Gear oil drain screw
2. Oil level plug
CAUTION:
Change the gear oil after the first 10 hours of operation, and every 100 hours or at 6-month intervals
thereafter. Otherwise the gear will wear quickly.
4. Remove the oil level plug to allow the oil to drain completely.
CAUTION:
Inspect the used oil after it has been drained. If the oil is milky, water is getting into the gear case
which can cause gear damage. Consult your dealer.
5. Use a flexible or pressurized filling device; inject the gear oil into the gear oil drain screw hole.
6. When the oil begins to flow out of the oil level plug hole, insert and tighten the oil level plug (If necessary,
change the seal spacer).
7. Insert and tighten the gear oil drain screw (If necessary, change the seal spacer).
2
1
