11
3.5 Trim angle adjustment of outboard motor
Remove the trim adjusting rod on the
clamping bracket, which has four holes.
Adjust the outboard motor to a suitable
position, and then insert the trim adjusting
rod into the corresponding hole to complete
the adjustment.
Note: Do not turn on the power supply when
adjusting the trim angle, so as to avoid accidents.
3.6 Handle angle adjustment
The handle of this product has the function of adjusting the angle up and
down, but it is not detachable.
When sailing, the handle can be rotated up
or down by up to 45°. When rotating up, the
handle can be directly lifted up. When
rotating downward, the handle needs to be
stretched outward and then rotated down.
Note: When rotating 45° down, the handle will
automatically keep the current angle, and you
need to press it down to continue.
