2. Tighten the air vent screw on the fuel tank cap.
3. Disconnect the fuel line if you are using an external fuel tank.
2.10 Trimming outboard motor
There are 4 or 5 holes provided in the clamp bracket to adjust the outboard motor trim angle.
1. Stop the engine.
2. Remove the trim rod from the clamp bracket
while slightly tilting the outboard motor up.
22
