Partner RP-330 - Printing and Cutting Positions

RP-330 Technical Manual
10
1.7 Printing and Cutting Positions
Center of the print dotline
Auto-cutter blade position
Manual-cutter position
[Units: mm(Al the numeric values are typical.)]
Appro *12.6
Paper feed direction
Appro *
30.5
Figure 1.7.1 Printing and Cutting Positions
NOTE: Numeric values used here are center values to be used in designing. The values may vary slightly as a result of
paper slack or variations in the paper. Take this into account when setting the cutting position of the autocutter.
