Parweld XTI-201 - TIG Welding Procedure; Fault Finding

www.parweld.com
10
FAULT
FINDING
Filler wire diameter Current range
1/16” (1.6 mm) 20 - 90
3/32” (2.4 mm) 65 - 115
1/8” (3.2 mm) 100 - 165
3/16” (4.8 mm) 200-350
The ller wire diameter specied is a guide only, other
diameter wires may be used according to the welding
applicaon.
Shielding gas selecon
Alloy Shielding gas
Aluminium &
alloys
Pure Argon
Carbon steel Pure Argon
Stainless steel Pure Argon
Nickel alloy Pure Argon
Copper Pure Argon
Titanium Pure Argon
Machine setup for TIG welding
DC TIG welding
1)Connect the torch to the - connecon and the gas
hose to the gas outlet.
2) Connect the trigger control plug on the torch to the
trigger socket.
3) Connect the Earth lead to the + connecon.
4) Set the process mode to 2T or 4T if you prefer a
latching trigger acon. (Note in 4T posion you must
press and release to start the process and press and
release again to stop the process)
5) Select DC output from (top posion)
6) Select HF start (boom posion)
7) Dial up the welding amperage required
8) Set the starng amperage at 50%
9) Set the down slope at 5 seconds
10) Set the post gas at around 5 seconds
You are now ready to weld. The above sengs are a
guide and you should adjust to suit the job you are
welding if you are unfamiliar with the machine try to
adjust only one parameter at a me so you become
familiar with its eect.
AC TIG welding
1)Connect the torch to the - connecon and the gas
hose to the gas outlet.
2) Connect the trigger control plug on the torch to the
trigger socket.
3) Connect the Earth lead to the + connecon.
4) Set the process mode to 2T or 4T if you prefer a
latching trigger acon. (Note in 4T posion you must
press and release to start the process and press and
release again to stop the process)
5) Select AC output from (centre posion)
6) Select HF start (boom posion)
7) Dial up the welding amperage required
8) Set the starng amperage at 50%
9) Set the down slope at 5 seconds
10) Set the post gas at around 5 seconds
11) Set the cleaning control to 0.
You are now ready to weld. The above sengs are a
guide and you should adjust to suit the job you are
welding if you are unfamiliar with the machine try to
adjust only one parameter at a me so you become
familiar with its eect. With AC TIG welding the
cleaning control is used to adjust the balance between
heang and cleaning the work
