Model
Stock Code 3M 4M 5M Model Description
XP300A -30E -40E -50E Welding Torch c/w Euro Fitting
Nozzles
Stock Code Description
A XP2002-10 Tapered Nozzle 3/8”/10mm
XP2002-13 Tapered Nozzle 1/2”/13mm
XP2002-16* Conical Nozzle 5/8”/16mm
XP2002-16L Conical Nozzle 5/8”/16mm-Extended
XP2002-19 Cylindrical Nozzle 3/4”/19mm
XP2002-19L Cylindrical Nozzle 3/4”/19mm-Extended
B XP3002-13 Tapered Nozzle 1/2”/13mm
XP3002-16 Conical Nozzle 5/8”/16mm
XP3002-16L Conical Nozzle 5/8”/16mm-Extended
XP3002-19 Cylindrical Nozzle 3/4”/19mm
XP3002-19L Cylindrical Nozzle 3/4”/19mm-Extended
Contact Tips
Stock Code Description
C XP2003-08 Contact Tip .030”/0.8mm M8 CuCrZr
XP2003-09 Contact Tip .035”/0.9mm M8 CuCrZr
XP2003-10 Contact Tip .040”/1.0mm M8 CuCrZr
XP2003-10A Contact Tip .040”/1.0mm Aluminium M8 CuCrZr
XP2003-12* Contact Tip .045”/1.2mm M8 CuCrZr
XP2003-12A Contact Tip .045”/1.2mm Aluminium M8 CuCrZr
XP2003-13 Contact Tip .052”/1.3mm M8 CuCrZr
D XP3003-08 Contact Tip .030”/0.8mm M10 CuCrZr
XP3003-09 Contact Tip .035”/0.9mm M10 CuCrZr
XP3003-10 Contact Tip .040”/1.0mm M10 CuCrZr
XP3003-10A Contact Tip .040”/1.0mm Aluminium M10 CuCrZr
XP3003-12 Contact Tip .045”/1.2mm M10 CuCrZr
XP3003-12A Contact Tip .045”/1.2mm Aluminium M10 CuCrZr
XP3003-13 Contact Tip .052”/1.3mm M10 CuCrZr
Liners
Stock Code Description
E XP2024-0-30 Steel Liner .023-.035”/0.6mm/0.9mm x 10ft/3m
XP2024-0-40 Steel Liner .023-.035”/0.6mm/0.9mm x 13ft/4m
XP2024-0-50 Steel Liner .023-.035”/0.6mm/0.9mm x 16ft/5mt
XP2024-12-30* Steel Liner .040-.045”/1.0mm/1.2mm x 10ft/3m
XP2024-12-40* Steel Liner .040-.045”/1.0mm/1.2mm x 13ft/4mt
XP2024-12-50* Steel Liner .040-.045”/1.0mm/1.2mm x 16ft/5m
NI XP2024PC-12-30 Polyamide-Copper Liner
.030-.045”/0.8mm-1.2mm x 10ft/3mt
XP2024PC-12-40 Polyamide-Copper Liner
.030-.045”/0.8mm-1.2mm x 13ft/4m
XP2024PC-12-50 Polyamide-Copper Liner
.030-.045”/0.8mm-1.2mm x 16ft/5mt
XP2024PS-12-30 Polyamide-Steel Liner
.030-.045”/0.8mm-1.2mm x 10ft/3m
XP2024PS-12-40 Polyamide-Steel Liner
.030-.045”/0.8mm-1.2mm x 13ft/4m
XP2024PS-12-50 Polyamide-Steel Liner
.030-.045”/0.8mm-1.2mm x 16ft/5m
Note: For ux core wire 1.6mm liner is recommended –
Stock Code: XP2023-16-30
Components
Stock Code Description
1 XP2004B* Di󰀨user-Plastic – M8 Head
NI XP2004C Di󰀨user-Ceramic – M8 Head
2 XP3004B Di󰀨user-Moulded c/w Ceramic Insert – M10 Head
NI XP3004C Di󰀨user-Ceramic – M10 Head
3 XP2005* Head Assembly – M8 Tips
4 XP3005 Head Assembly – M10 Tips
5 XP2006A* Aluminium Heat Shield – M8 Head
NI XP2006B Heat Shield Moulded – M8 Head
6 XP3006A Aluminium Heat Shield – M10 Head
NI XP3006B Heat Shield Moulded – M10 Head
7 XP3001 Swan Neck
8 XP2016 Lock Nut M12
9 XP3008 Ball Joint and Cable Support
10 XP2009 Handle Lock Nut
11 XP3010-30 Cable Assembly x 3m/10ft
XP3010-40 Cable Assembly x 4m/13ft
XP3010-50 Cable Assembly x 5m/16ft
12 XP2011 Cable Terminal Female
13 XP2012 Handle Kit c/w Lock Nut
14 XP2013 Hanger Hook
15 XP2014 Trigger
16 XP2015 Cable Terminal Male
17 XP3017 Cable Support
18 XP2018 Air Cooled Gun Plug Housing c/w Nut
19 XP2019 Gun Plug Screw
20 XP2020 Gun Plug Nut
21 Spring Pin 2 Spring Pin Assembly
22 XP2022 Gun Plug Body c/w Spring Pins
23 XP2023 Gun Plug Body O Ring
24 XP2025 Liner Nipple O Ring
25 XP2026 Liner Retaining Nut
* Denotes Standard Build
