Model
Stock Code 3M 4M 5M Model Description
XP350A -30E -40E -50E Welding Torch c/w Euro Fitting
Nozzles
Stock Code Description
A XP3002-13 Tapered Nozzle 1/2”/13mm
XP3002-16* Conical Nozzle 5/8”/16mm
XP3002-16L Conical Nozzle 5/8”/16mm-Extended
XP3002-19 Cylindrical Nozzle 3/4”/19mm
XP3002-19L Cylindrical Nozzle 3/4”/19mm-Extended
Contact Tips
Stock Code Description
B XP3003-10 Contact Tip .040”/1.0mm M10 CuCrZr
XP3003-10A Contact Tip .040”/1.0mm Aluminium M10 CuCrZr
XP3003-12* Contact Tip .045”/1.2mm M10 CuCrZr
XP3003-12A Contact Tip .045”/1.2mm Aluminium M10 CuCrZr
XP3003-13 Contact Tip .052”/1.3mm M10 CuCrZr
XP3003-14 Contact Tip .055”/1.4mm M10 CuCrZr
XP3003-16 Contact Tip 1/16”/1.6mm M10 CuCrZr
Liners
Stock Code Description
C XP3524-12-30* Steel Liner .040”/1.0mm-.045”/1.2mm x 10ft/3m
XP3524-12-40* Steel Liner .040”/1.0mm-.045”/1.2mm x 13ft/4m
XP3524-12-50* Steel Liner .040”/1.0mm-.045”/1.2mm x 16ft/5m
XP3524-16-30 Steel Liner .063”/1.6mm x 10ft/3m
XP3524-16-40 Steel Liner .063”/1.6mm x 13ft/4m
XP3524-16-50 Steel Liner .063”/1.6mm x 16ft/5m
NI XP2024PC-12-30 Polyamide – Copper Liner
.030-.045”/0.8mm-1.2mm x 10ft/3mt
XP2024PC-12-40 Polyamide – Copper Liner
.030-.045”/0.8mm-1.2mm x 13ft/4m
XP2024PC-12-50 Polyamide – Copper Liner
.030-.045”/0.8mm-1.2mm x 16ft/5m
XP3524PC-16-30 Polyamide – Copper Liner
.045-.063”/1.2mm-1.6mm x 10ft/3m
XP3524PC-16-40 Polyamide – Copper Liner
.045-.063”/1.2mm-1.6mm x 13ft/4m
XP3524PC-16-50 Polyamide – Copper Liner
.045-.063”/1.2mm-1.6mm x 16ft/5m
XP2024PS-12-30 Polyamide – Steel Liner
.030-.045”/0.8mm-1.2mm x 10ft/3m
XP2024PS-12-40 Polyamide – Steel Liner
.030-.045”/0.8mm-1.2mm x 13ft/4m
XP2024PS-12-50 Polyamide – Steel Liner
.030-.045”/0.8mm-1.2mm x 16ft/5m
XP3524PS-16-30 Polyamide – Steel Liner
.045-.063”/1.2mm-1.6mm x 10ft/3m
XP3524PS-16-40 Polyamide – Steel Liner
.045-.063”/1.2mm-1.6mm x 13ft/4m
XP3524PS-16-50 Polyamide – Steel Liner
.045-.063”/1.2 mm-1.6mm x 16ft/5m
Components
Stock Code Description
1 XP3004B* Di󰀨user – Moulded c/w Ceramic Insert – M10 Head
NI XP3004C Di󰀨user – Ceramic – M10 Head
2 XP3505* Head Assembly-M10 Tips
3 XP3506A* Aluminium Heat Shield – M10 Head
NI XP3506B Heat Shield – Moulded – M10 Head
4 XP3501 Swan Neck
5 XP3507 Lock Nut M14
6 XP3008 Ball Joint and Cable Support
7 XP2009 Handle Lock Nut
8 XP3510-30 Cable Assembly x 3m/10ft
XP3510-40 Cable Assembly x 4m/13ft
XP3510-50 Cable Assembly x 5m/16ft
9 XP2011 Cable Terminal Female
10 XP2012 Handle Kit c/w Lock Nut
11 XP2013 Hanger Hook
12 XP2014 Trigger
13 XP2015 Cable Terminal Male
14 XP2016 Lock Nut M12
15 XP3017 Cable Support
16 XP2018 Air Cooled Gun Plug Housing c/w Nut
17 XP2019 Gun Plug Screw
18 XP2020 Gun Plug Nut
19 Spring Pin 2 Spring Pin Assembly
20 XP2022 Gun Plug Body c/w Spring Pins
21 XP2023 Gun Plug Body O Ring
22 XP2025 Liner Nipple O Ring
23 XP2026 Liner Retaining Nut
* Denotes Standard Build
