5
Watch for re, and keep a re extinguisher nearby. Be aware that
welding on a ceiling, oor, bulkhead, or partition can cause re on
the hidden side.
Do not weld on closed containers such as tanks, drums, or pipes,
unless they are properly prepared according to local regulations
Connect work cable to the work as close to the welding area as
practical to prevent welding current from travelling along, possibly
unknown paths and causing electric shock, sparks, and re hazards.
Wear oil-free protective garments such as leather gloves, heavy
shirt, cufess trousers, high shoes, and a cap. Remove any
combustibles, such as a butane lighter or matches, from your person
before doing any welding.
FLYING METAL can injure eyes.
Welding, chipping, wire brushing, and grinding cause sparks and
ying metal. As welds cool they can throw off slag. Wear approved
safety glasses with side shields even under your welding helmet.
BUILDUP OF GAS can injure or kill.
Shut off shielding gas supply when not in use. Always ventilate
conned spaces or use approved air-supplied respirator.
HOT PARTS can cause severe burns.
Do not touch hot parts with bare hands.
Allow cooling period before working on gun or torch.
To handle hot parts, use proper tools and/or wear heavy, insulated
welding gloves and clothing to prevent burns.
ELECTRICAL AND MAGNETIC FIELDS
Can affect pacemakers Pacemaker wearers keep away.
Wearers should consult their doctor before going near arc welding,
gouging, or spot welding operations.
Welders should use the following procedures to minimize exposure
to Electrical and Magnetic Fields
Route the electrode and work cables together. Secure them with
tape when possible.
Never coil the torch or work cable around your body.
Do not place your body between the torch and work cables. Route
cables together on the same side of your body.
Connect the work cable to the work piece as close as possible to the
area being welded.
Keep the welding power source and cables as far away from your
body as possible.
NOISE can damage hearing.
Noise from some processes or equipment can damage hearing.
Wear approved ear protection if noise level is high.
Shielding gas cylinders contain gas under high pressure.
CYLINDERS can explode if damaged.
Protect compressed gas cylinders from excessive heat, mechanical
shocks, physical damage, slag, open ames, sparks, and arcs.
Install cylinders in an upright position by securing to a stationary
support or cylinder rack to prevent falling or tipping. Keep cylinders
away from any welding or other electrical circuits. Never drape a
welding torch over a gas cylinder. Never allow a welding electrode to
touch any cylinder. Never weld on a pressurized cylinder - explosion
will result. Use only correct shielding gas cylinders, regulators,
hoses, and ttings designed for the specic application; maintain
them and associated parts in good condition.
Turn face away from valve outlet when opening cylinder valve.
Use the right equipment, correct procedures, and sufcient number
of persons to lift and move cylinders.
Read and follow instructions on compressed gas cylinders,
associated equipment, and Compressed Gas Association (CGA)
recommendations.
2.0 Product Description
This welding machine is manufactured using advanced inverter
technology. The input voltage is rectied to DC and then inverted to
high frequency AC voltage, before being converted back to DC for
the output .This allows the use of a much smaller transformer and so
allowing weight saving and improved power efciency.
3.0 Technical
Specications
SAFETY
Foot Control
3 Button Trigger
Control
XTT202 AC/DC P
U
2
U
2
I
2
I
2
X
X
10A/10.4V-200A/18V
10A/20.4V-170A/26.8V
25%
200A 200A
170A 170A
90A 110A
90A 110A
70A 90A
70A 90A
18V 18V
26.8V 26 8V.
13.6V 14.4V
23.6V 24.4V
12.8V 13.6V
12.8V 23.6V
25% 25%
25%60%
60%
60%
60%
100%
100%
100%
100%
F
U =
1
IP23S
MMA
220V/230V/240V
TIG
1~50/60Hz
S
S
BEWDLEY BUSINESS PARK,
PARWELD LTD,
LONG BANK BEWDLEY,
WORCESTERSHIRE,
DY12 2TZ,
ENGLAND.
I max=42.5A
1
I max=35.4A
1
I eff=17.7A
1
I eff=21.3A
1
ISO/IEC 60974-1
U =
0
70V
1~
f1
f2
U =
0
70V
AC
AC
5A/10.2V-200A/18V
DC
DC
5A/20.2V-170A/26.8V
Control Plug Wiring
