Paslode Positive Placement PF150S-PP - TOOL AND FASTENER SPECIFICATIONS; TOOL SPECIFICATIONS; FASTENER SPECIFICATIONS

3
TOOL SPECIFICATIONS
MODEL NO. PF150S-PP (Part# 502300)
HEIGHT
11.7”
WIDTH
LENGTH 17.4"
WEIGHT 6 lbs. 5 oz.
OPERATING PRESSURE 90 to 120 psi (6.2 to 8.3 bar)
FASTENER SPECIFICATIONS
TOOL AIR FITTINGS:
This tool uses a 1/4” N.P.T. male plug. The fitting must be capable of discharging
tool air pressure when disconnected from the air supply.
OPERATING AIR PRESSURE:
90 to120 psi (6.2 to 8.3 bar). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
NAIL LENGTH
1-1/2”
SHANK DIAMETER .131-.148
TOOL AND FASTENER SPECIFICATIONS
NAIL COATINGS
Heat Treated,
Galvanized Heat Treated
MAGAZINE TYPE
30 Degree, Strip
3.7”
