PassTime USA CONFIDENTIAL
PassTime GPS Install Guide v 2.5 Pg. 1 December 2010
Overview
This document defines and specifies the GPS, available under this version:
• Model name: PTE-2 – HW Version 1.0 ; SW Version 1.0
Installation
Installing the GPS unit is a simple procedure. All device harness connections will be made in close
proximity to the steering column in the wiring harness, which runs up the column towards the steering
wheel. Due to the long-range operational nature of the GPS unit, all connections should be soldered and
taped or heat shrunk using the correct soldering and insulation techniques to provide high-quality
connections. However, you may leave the unit itself out in the open and within your line of sight. The
quality of your installation is the single most important factor in this product’s success.
This section covers:
• Wiring the PassTime Device Harness into the ignition switch harness. (Do not plug the GPS unit
into the harness until you have made all connections.)
• Mounting the GPS unit.
Before You Start
• Record the 15-digit IMSI number from the unit:
• Record the make, model, and year of the vehicle in which the unit is being installed:
Make
Model Year
Package Contents
Each GPS unit contains the following:
(1) GPS location unit (Note: Please confirm that the electronic serial numbers (ESNs) on the unit and on
the bag match.)
(1) PassTime Device Harness
