Patlite LR4 - Page 37

37
Body
LED Unit
LED Unit
<Locked>
<Unlocked>
■Positioning Mark
<Unlocked>
■
Positioning Mark
<Locked>
■Removal
While holding LED unit, turn the LED unit counterclockwise,
until it unlocks, then pull it upwards to remove.
to remove it.
< LED Unit to LED Unit >
■Attachment
Align the Positioning Mark after insertion, then turn the unit
clockwise to lock it.
Align the Positioning Mark
after inserting.
