Patlite LR4 - Page 63

63
φ40
120°
120°
(Unit: mm)
Mounting Dimensional Drawing■
SZP-003[W/U/K]
∅
60
Pole
∅21.7
(∅29)
Mounting Hole
(φ5×3places)
Wire Distribution
Hole (φ12)
0.6 N m
Recommended Torque
M4
Screw/Nut
35
（
6
）
SZP-003 [W/U/K]
Circular Bracket
Accessories:
Waterproof Packing
Pole Waterproof Ring
Binding Head Tapping Screw ( 2 pcs.)
POLE22-0100AN,POLE22-0300AN
POLE22-0100ANK,POLE22-0300ANK
Compatible Pole
Specifications
Protection Rating
Mounting Location
Model
Material
SZP-003[W/U/K]
Remarks
Mass (Tolerance ±10%)
Indoor Only
IP65 (with product attached）
PC
0.03kg
Outer Dimensions
Mounting Dimensional Drawing
※No Accessories
There are no contents of controlled
substances exceeding the threshold
for the RoHS Directive.
（Unit
:
mm
）
-
PJ
LR4
-
PJLR5
,
,
QJ
-
PJ
LR6
QJ
Compatible Models
KT
-
LR7 KT
※
1
※
1
003
Circular Bracket
↓
SZP
-
Model
W
Body Color
Off-white
Silver
Model Number Configuration
U
Black
(※1)Requiredpoleisnotincludedwith.
KT
K
