Patrol PC RT-12i - Hard Drive Access (No Antennas); Hard Drive Removal Procedure

37 | P a g e
Hard Drive Access for Units with No Internal Antennas Installed
ESD Warning: The internal components of the RT-12i tablet are sensitive to electrostatic discharge. Please
observe precautions for handling electrostatic sensitive devices, including proper grounding prior to opening
the unit.
1. Remove the power cable from the computer.
2. Remove the 8 screws circled below.
3. Remove the top cover. The hard drive is now accessible. Pull out the hard drive tray.
NOTE: An easy way to get it out is to insert a screw driver into the small hole in the tray and use the screw
driver as a lever to unseat the hard drive tray.
4. To remove the hard drive from the hard drive tray, remove the four screws circled below.
