Paul FOCUS 200 Base - Page 30

30
Air flow
45 to 200 m³/h
Efficiency criterion
0,31 Wh/m³ (at 135 m³/h / 100 Pa)
Heat recovery rate acc. PHI
91 % (at 135 m³/h / 100 Pa); FOCUS 200
Sound, device emission
(acc. to DIN EN ISO 3743-1, distance of 3 m)
30 dB(A) (at 155 m³/h / 100 Pa)
24 dB(A) (at 200 m³/h / 100 Pa)
Tab. 13: Operating data
p-𝑽
󰇗
-characteristic curve
Please note:
The numerical values of the
p-𝑉
󰇗
-characteristic curve
which are illustrated in the
chart indicate the power
consumption in [W] in the
respective operating points.
Tab. 14: Chart 3, p-𝑉
󰇗
characteristic curve
