Page 34
FS.AdJ..
FULL SCALE OFFSET REGULATION
Measure the analogue output value with a multimeter to perform the full scale (FS) calibration.
Use the keys
and to regulate the analogue output. Hold the key for a quick change.
Press key
to go back to the ANALOG menu.
This procedure is available to the user for adjustment, for each selectable range. In the case of a full
reset of the setup memory (PC Configurator), they are restored values to the factory calibration.SERIAL
