Page 50
FILTER - SETTING FILTER PARAMETERS
d1G.bAn.
WEIGHT FILTER VALUE [1201]
This parameter adjusts not only the refresh rate of the display, but specially the serial and analogue
output. The maximum refresh rate of the display is limited to 25 Hz
High filter values speed up the weight update.
Low values of the filter slow down the weight update.
Factor
(Hz)
Settling
Time
(mS)
ADC Freq
(Hz)
N readings
Monotony
Time (mS)
Oscillation
time (mS)
Oscillation
range (div)
MANUAL [0] Selectable Settable Settable Settable Settable
50 [1] 20 250 5 20 4000 10
25 [2] 40 100 5 40 3000 12
10 [3] 100 50 5 80 2500 16
5 [4] 200 50 10 100 2000 20
2 [5] 500 50 25 250 1500 25
1,25 [6] 800 12,5 10 300 1500 25
1 [7] 1000 12,5 12 400 1500 25
0,7 [8] 1500 12,5 19 500 1200 30
0,5 [9] 2000 12,5 25 600 1000 30
Default: 2 Hz
The following parameters are visible and therefore can be set, only if the parameter selection is MANUAL.
C. rAtE.
ADC SPEED [1202]
With this parameter, the frequency of weight acquisition is adjusted. If the parameter changes to values
higher than 12.5 Hz, the weight must be stable. In case of instability the instrument will immediately
indicate an error message.
Selectable Values:
12,5 [0]
50 [1]
100 [2]
250 [3]
1000 [4]
AJErAG.
NUMBER OF READINGS ON AVERAGE [1203]
With this parameter you set the number of readings that the filter will use to establish the average
weight value.
Values: from 0 to 50.
