PARAMETERS DEFINED BY THE MANUFACTURER
Index Sub-Index Name Description Type Attribute
2000h
0
UD_STATUS
Sub-index number(1) U8 R
1 Status Register U16 R/W
2001h
0
UD_LORDO
Sub-index number(1) U8 R
1 Gross weight S32 R
2002h
0
UD_NETTO
Sub-index number(1) U8 R
1 Net weight S32 R
2003h
0
UD_PICCO
Sub-index number(1) U8 R
1 Peak S32 R
2004h
0
UD_IN
Sub-index number(1) U8 R
1 Digital input U8 R
2005h
0
UD_OUT
Sub-index number(1) U8 R
1 Digital output U8 R
2006h
0
UD_COMMAND
Sub-index number(1) U8 R
1 Command Register U16 R/W
2007h
0
UD_DATA
Sub-index number(1) U8 R
1 Data Register U32 R/W
2008h
0
UD_MONITOR_R
Sub-index number(1) U8 R
1 Monitor Register (reading) U16 R
2009h
0
UD_MONITOR_W
Sub-index number(1) U8 R
1 Monitor Register (writing) U16 W
200Ah
0
UD_W_VAL
Sub-index number(1) U8 R
1 Net weight weighing S32 R
200Bh
0
UD_W_CODE
Sub-index number(1) U8 R
1 Weighing code S32 R
200Ch
0
UD_SET_1
Sub-index number(1) U8 R
1 Set-Point 1 S32 R/W
200Dh
0
UD_SET_2
Sub-index number(1) U8 R
1 Set-Point 2 S32 R/W
200Eh
0
UD_PORTATA
Sub-index number(1) U8 R
1 Load cells capacity S32 R/W
200Fh
0
UD_SENS
Sub-index number(1) U8 R
1 Load cells sensitivity U16 R/W
2010h
0
UD_DIV
Sub-index number(1) U8 R
1 Weight division value U8 R/W
