Page 83
Index Sub-Index Name Description Tipo Attributo
2022h
0
UD_FUN_IN1
Sub-index number (1) U8 R
1 Input 1 function U8 R/W
2023h
0
UD_FUN_IN2
Sub-index number (1) U8 R
1 Input 2 function U8 R/W
2024h
0
UD_FUN_OUT1
Sub-index number (1) U8 R
1 Output mode 1— Function U8 R/W
2025h
0
UD_LOG_OUT1
Sub-index number (1) U8 R
1 Output mode 1— Logic U8 R/W
2026h
0
UD_POL_OUT1
Sub-index number (1) U8 R
1 Output mode1— Polarity U8 R/W
2027h
0
UD_STAB_OUT1
Sub-index number (1) U8 R
1 Output mode 1— Stability U8 R/W
2028h
0
UD_IST_OUT1
Sub-index number (1) U8 R
1 Hysteresis input 1 S32 R/W
2029h
0
UD_T_OUT1
Sub-index number (1) U8 R
1 Timing input 1 U16 R/W
202Ah
0
UD_R_OUT1
Sub-index number (1) U8 R
1 Delay input 1 U16 R/W
202Bh
0
UD_FUN_OUT2
Sub-index number (1) U8 R
1 Output mode 2— Function U8 R/W
202Ch
0
UD_LOG_OUT2
Sub-index number (1) U8 R
1 Output mode 2— Logic U8 R/W
202Dh
0
UD_POL_OUT2
Sub-index number (1) U8 R
1 Output mode 2— Polarity U8 R/W
202Eh
0
UD_STAB_OUT2
Sub-index number (1) U8 R
1 Output mode 2— Stability U8 R/W
202Fh
0
UD_IST_OUT2
Sub-index number (1) U8 R
1 Hysteresis input 2 S32 R/W
2030h
0
UD_T_OUT2
Sub-index number (1) U8 R
1 Timing input 2 U16 R/W
2031h
0
UD_R_OUT2
Sub-index number (1) U8 R
1 Delay input 2 U16 R/W
2032h
0
UD_ANA_T
Sub-index number (1) U8 R
1 Analogue Fixed Tare S32 R/W
2033h
0
UD_ANA_FS
Sub-index number (1) U8 R
1 Analogue Full Scale S32 R/W
2034h
0
UD_ANA_M
Sub-index number (1) U8 R
1 Analogue Output Mode U8 R/W
2035h
0
UD_ANA_R
Sub-index number (1) U8 R
1 Analog output range U8 R/W
