v1.3 | 13
A80 REFERENCE GUIDE
3 .7.2 SAM, AND SD CARD SLOT LOCATION
The SAM and Micro SD card slots are located at the back of the device.
3 .7.3 SAM, AND SD CARD INSTALLATION
1. Slide the back cover down to remove it
from the terminal.
2. Insert the SAM and/or SD card into the slot
with contacts facing down and the clipped
corner of the card facing the upper right.
