PB EC Series - Page 14

12
PIPING & CONTROLS
Figure 3.4: Steam; Near Boiler Piping - EC(T)-06
STEAM
SUPPLY
CONDENSATE RETURN
24"
32-1/4"
N.W.L.
FLOOR LINE
4
3
1
5
10
16
20
15
12
17
14
14
14
19
12
16
18
16
18
NORMAL
WATER LINE
BOTTOM
OF
HEADER
2" TO 4" BELOW NORMAL WATER LEVEL
TOP OF ELBOW
2
1
1
2
11
13
6
7
7
8
9
21
NEAR BOILER PIPING - DUAL SUPPLY: MODEL EC(T)-06
EC8056 R2
NOTE
: Nipple lengths may require modification
due to variations in thread engagement and machining. Contractor should carry assorted length nipples. Not responsible for discrepancies.
