Motherboard User’s Guide
Pin Signal
1 CD_L
2GND
3GND
4CD_R
Here is a list of CD_IN pin assignments.
Expansion Slots
This motherboard has one PCI Ex16 slot (MCP61S only supports PCI Express
x8), one PCI Ex1 slot and two 32-bit PCI slots.
