54
L510010-03
C.C.
VISUAL INSPECTION
It is important for the owner/operator to visually inspect
the complete engine assembly at regular intervals. Most
often, costly repairs can be avoided if potential problems
are corrected before there is a failure.
Inspect the complete engine assembly for obvious fuel,
oil, water or exhaust leaks. Check for loose, damaged
or missing parts. Check all hose clamps for adequate
tightness. Check the electrical system for loose or dirty
connections or damaged wiring.
ENGINE MAINTENANCE - 11
TRANSMISSION FLUID CAPACITIES
Model All Models Type
PCM, 1:1 Ratio
1,2
2.0 Quarts (1.9 L) DEXRON III
PCM, 1.23:1 Ratio
1,2
2.0 Quarts (1.9 L) DEXRON III
Hurth (Exc. V-Drive), All Ratios
1,2
4.0 Quarts (3.79 L) DEXRON III
Hurth V-Drive, All Ratios
1,2
4.5 - 5.0 Quarts (4.26 - 4.73 L) DEXRON III
Walters RV-36D V-Drive 1.5 Quarts (1.42 L) SAE 30
1 - Capacities are dependent on installation angle. Oil capacities are approximate, and may not include capacity
needed for transmission cooler and oil lines. Always use the dipstick to determine the exact quantity of oil required.
2 - Check the transmission fl uid level at operating temperature and immediately after shutdown of the engine.
Touch up scratches, nicks and corrosion damage to the
exterior fi nish of the engine. Spray paint may be obtained
from your local PCM Engines dealer.
Protect engine fi nish from corrosion by periodically
spraying the engine exterior fi nish with a rust
preventative oil (such as WD-40).
ENGINE FLUID CAPACITIES
Model MP 5.0L / 5.7L MP 6.0L MP 8.1L
Crankcase Oil Capacity
W / New Filter 4 Quarts (3.8 L)
1
5 Quarts (4.75 L)1
7 Quarts (6.65 L)
1
Fresh Water Cooling
System Capacity 23 Quarts (21.85 L) 18 Quarts (17.01 L) 33 Quarts (31.35 L)
