PCM 2003 5.0L MPI User Manual

57
L510010-03
C.C.
ENGINE SPECIFICATIONS - 12
Figure 12-1 V-8 Firing Orders
1
7
c
6
4
2
8
3
5
1
3
5
7
2
4
6
8
1
3
5
7
2
4
6
8
5.0 / 5.7 Liter
LH ROTATION
FRONT
6.0 / 8.1 Liter
LH ROTATION
FRONT
NO
DISTRIBUTOR
FIRING ORDER:
1-8-4-3-6-5-7-2
FIRING ORDER:
1-8-7-2-6-5-4-3
FLYWHEEL END OF ENGINE
ALL V-8 MODELS
Rotation
TUNE-UP SPECIFICATIONS
Model
MP 5.0L (275 HP) MP 8.1L(STD) (385 HP)
MP 5.7L (330 HP) MP 6.0L (370 HP) MP 8.1L (HO) (425 HP)
Spark Plug Type AC - MR43LTS
NGK - PZTR5A-15 Denso - TJ14R-P15
Spark Plug Gap
0.060 in. 0.060 in. 0.060 in.
(1.52 mm) (1.52 mm) (1.52 mm)
Ignition Timing
Fixed, Fixed, Fixed,
Not Adjustable Not Adjustable Not Adjustable
Firing Order
1-8-4-3-6-5-7-2 1-8-7-2-6-5-4-3 1-8-7-2-6-5-4-3
(LH Rotation) (LH Rotation) (LH Rotation)
