5.2 Print Problem
Problem Possible Cause Recovery Procedure
Not Printing
Check if interface cable is well
connected to the interface connector.
Re-connect cable to interface.
The serial port cable pin configuration is
not pin to pin connected.
Please replace the cable with pin to pin
connected.
The serial port setting is not consistent
between host and printer.
Please reset the serial port setting.
The port specified in the Windows driver
is not correct.
Select the correct printer port in the
driver.
The Ethernet IP, subnet mask, gateway
is not configured properly.
Configure the IP, subnet mask and
gateway.
No print on the
wristband
Wristband loaded not correctly.
Follow the instructions in loading the
media.
Continuous feeding
wristbands
The printer setting may go wrong.
Please do the initialization and black
mark calibration.
Paper Jam
Black mark sensor sensitivity is not set
properly (sensor sensitivity is not
enough)
Calibrate the black mark sensor.
Make sure wristband size is set properly.
Set wristband size exactly as installed
paper in the labeling software or
program.
Wristbands may be stuck inside the
printer mechanism near the sensor area.
Remove the stuck wristband.
Poor Print Quality
Top cover is not closed properly.
Close the top cover completely and
make sure the right side and left side
levers are latched properly.
Wrong power supply is connected with
printer.
Check if 24V DC output is supplied by
the power supply.
Check if supply is loaded correctly.
Reload the supply.
Check if dust or adhesives are
accumulated on the print head.
Clean the print head.
Check if print density is set properly.
Adjust the print density and print
speed.
Check print head test pattern if head
element is damaged.
Run printer self-test and check the print
head test pattern if there is dot missing
in the pattern.
To Next Page
