Peak 212 - Power Unit Assembly (Three-Phase); Hydraulic Valve Illustration

26
Three-phase 380V, 50Hz manual power unit Parts list
Item
Part#
Description
Qty
Item
Part#
Description
Qty
1
71150022
AMGO Aluminum
label
1
19
10420148
screw
2
2
81400300
screw
2
20
80101022
Cover of Motor
1
3
81400363
Motor connecting
shaft
1
21
10420070
Push button
1
4
81400362
Manifold block
1
22
81400560
Throttle valve
1
5
10209149
Wash
φ
6
4
23
81400266
Relief valve
1
6
81400276
End plug
1
24
81400284
Plug
1
7
81400259
Red plastic plug
1
25
81400452
Pin
1
8
85090142
Hex Bolt
4
26
81400451
Handle for release
valve
1
9
81400292
Gear pump
1
27
10209020
Plastic ball
1
10
81400366
Washφ8
1
28
81400421
Nut for release
valve
1
11
10209034
Socket bolt
2
29
81400422
Shim for release
valve
1
12
81400295
O ring
2
30
81400449
Valve seat
1
13
81400365
Tie
1
31
81400567
Release valve
1
14
10209152
Magnet
1
32
81400566
Check valve
1
5
85090167
Filter
1
33
81400367
Oil return pipe
1
16
81400290
Motor
1
34
81400364
Clamps
1
17
81400309
Motor connecting
shaft
1
35
81400263
Oil tank cap
1
18
81400348
AC connector
1
36
81400319
Oil tank
1
e. Illustration of hydraulic valve for hydraulic power unit
Oil Out
let
Oil return
port
Relief valve
Throttle
valve
Release
valve
Check valve
Fig. 40
Release
valve
