4. Front Panel Layout

1. Digital Display

2. Data Hold Button

3. MAX/MIN Button

4. Backlight Button

5. Mode/REL Button

6. Rotary Function switch

7. V Ω Cap mA E2 Jack

8. COM E1 jack

9. P2 Jack

10. P1 jack

-34-
