PeakTech 2705 User Manual

4.1. Button Function Operation
HOLD button
The HOLD function allows the meter to "freeze" a measurement for
later reference.
1. Press the HOLD button to “freeze” the reading on the indicator.
The “HOLD” message will be appear in the display.
2. Press the HOLD button again to return to normal operation.
MAX/MIN button
The MAX/MIN function allows the meter to capture the highest or
lowest measurement for later reference.
1. Press the MAX/MIN button to begin measurement. The indicator
“MAX” or “MIN” will appear in the display.
2. If the “MAX MIN” messages are flashing, the instrument is in
MAX/MIN mode but not recording, press the MAX/MIN button to
select a mode.
3. To return to normal AUTO measurement mode, hold down the
MAX/MIN button for 2 seconds.
Backlight
Press the key for to turn on the display backlight function. The
backlight will automatically turn off after 15 seconds.
MODE/REL button
To select AC or DC measurement when in Voltages, mA , uA ,Ω,
, ))) . RELATIVE ZERO BUTTON:
For convenient readings comparison & offset when in low
resistance test.
-35-
