Peavey CD Mix 9072A

CD/PHONO INPUTS:
Phono position:
Input Sensitivity: -50 dB (3 mV)
Input Impedance: 47K ohms
Max Input Level @ 1 kHz: -20 dBV (100 mV)
CD position:
Input Sensitivity: -10 dB (.316 Volts)
Input Impedance: 47K ohms
Max Input Level: +I8 dBV (8 Volts)
LINE INPUTS:
Input Sensitivity: -10 dB (.316 Volts)
Input Impedance: 8.3K ohms
Max Input Level: +I8 dBV (8 Volts)
MICROPHONE INPUTS (LOW-Z):
Input Sensitivity: -70 dB (.3 mV)
Input Impedance: 3K ohms
Max Input Level: +6 dBV (2 Volts)
MICROPHONE TALKOVER:
Attenuation (voice-over switch enabled or automatic voice-over enabled):
12dB
FREQUENCY RESPONSE:
Phono Inputs (RIAA): +O/-3 dB (20 Hz to 20 kHz)
Line Inputs: +O/-3 dB (20 Hz to 20 kHz)
Headphone: +O/-3 dB (40 Hz to 20 kHz)
SIGNAL-TO-NOISE RATIOS:
Phono: > 70 dB
Line: > 90 dB
DISTORTION:
Less than .Ol%
EQUALIZATION:
63 . . +12dBat63Hz -
160:
*I2 dB at 160 Hz
400: &I2 dB at 400 Hz
1 K:
+12dBatl kHz
2.5K:
+I 2 dB at 2.5 kHz
6.3K:
+I 2 dB at 6.3 kHz
16K: U2dBat 16 kHz
MICROPHONE EQ:
Low: +I5 dB at 50 Hz
Mid: +I2 dB at 600 Hz
.
HI : +_15dBatlOkHz
13
