(12, 13, 14)
Phone/CD
or Line selector switch:
Allows selection of phone/CD (L and
R)
or line (L and
R)
inputs. The “LINE”
position of this switch selects the line input, and the “CD-Phono” position selects
the CD/phone input.
(15, 16, 17) Channel Level slider:
A stereo slider that determines the output
level of the particular
channe
(18, 19, 20, 21) Cue switches:
When placed in the right-hand position each of these switches routes a
channel’s signal to the cue system.
When placed in the left-hand position each these switches routes the channel
signal out of the cue system.
Note: Channel
1
cueing is de-selected when the MIC input position is selected.
Headphone/Cue system:
(22)
Cue/PGM
Select switch:
When placed in the PGM position, this switch delivers headphone monitoring of
all stereo program material present at the outputs. The
PGM/Cue
position
delivers monitoring of the program (output) material to the left earcup of the
headphones. Material present on the cue bus (see Cue switches [I 2 thru
141)
will be heard in the right earcup of the headphones.
The Cue position delivers cue material, in stereo, to the headphones’ left and
right
earcups.
(23) Program Headphone Level slider:
Sets PGM sound levels that are available at the headphone socket when
program is selected.
(24) Channel Cue Headphone Level slider:
Sets Cue sound levels that are available at the headphone socket when cue is
selected.
(25) Headphone jack:
Stereo headphones patched in at this point will allow monitoring of program
material or cueing system. Note: Do not use mono headphones with this
system.
Crossfader:
(26) Crossfade assign switches:
The left-hand switch assigns channel 1, 2 , 3, or 4 to the left-hand side of the
crossfader. The right-hand switch assigns channel 1, 2, or 3 to the right-hand
side of the crossfader.
6
