Peavey PV - Bodypack Transmitter

19
21
22
23
24
25
26
27
1720 18
(17) Power / Mute Button
(18) Mic Jack
(19) IR Port
(20) Power / IR / Mute indicator
(21) Transmitter Antenna
(22) Detachable Belt Clip
(23) Mode with LT & GT
(24) Volume Adjustment
(25) Guitar Cable for guitar
wireless system
(26) Lavalier Mic for lavalier
wireless system
(27) Headphone Microphone for
headset wireless system
Green Ready
Flashing
green
Controls locked
Amber
Mute on
Flashing red
IR transmitter in process
Glowing
red
Battery power low
Pulsing
red on startup
Batteries dead(transmitter cannot be turned
on until batteries are changed)
Pulsing
synchronization
red after
Transmitter and receiver incompatible
BODYPACK TRANSMITTER
PV
®
16 Channel Dual Receiver Body Pack Transmitter
