mines the level of the effect that is routed thru the AUX "E" Pan
control.
PAN (28)
Assigns AUX “3'’ return to Left, Right, or both. Must be used neon
junction with AUX "B" Return Level.
AUX C RETURN SECTION
TO AUX A (29)
Allows the AUX "C" return to be assigned to the AUX A" mix.
TO AUX B (30)
Allows the AUX "C return to be assigned to the AUX ‘ B" mix.
LEVEL (31)
Controls the level of the AUX "C" Return When an outboard effects
device is patched into the AUX "C" patch loop, this control deter-
m nes the level of the effect that is routed thru the AUX "C" Pan
control
PAN (32)
Assigns AUX "C" Return to L & R or Subs 1, 2, 3, and 4. Must be
used in conjunction with assignment switches 30 thru 32.
PFL (33)
The "in’ position ot this switch assigns the AUX "C" Return to PFL.
L-R (34)
The ‘in" position of this switch routes the AUX ”C" Return thru
AUX "C" Pan control cirecty to left right, or both. Tne "out" posi
tion removes AUX "C" from L and R.
1-2 (35)
The "in' position ol this switch routes the AUX "C" Return thru
AUX C‘ Pan control to Sub 1, Sub 2. or both. The ‘‘out" position
removes AUX "C" from Subs 1 and 2
3-4 (36)
The "in ’ position of this switch routes the AUX "C" Return thru
AUX ‘ C" Pan control to Sub 3. Sub 4. or both The "out' position
removes AUX "C" from Subs 3 and 4.
Note: Assignment switching works in conjunction with AUX "C" Pan
control 32.
SUB 1 SECTION
PAN (37)
For stereo operation PAN is used to "crossfade the Submaster to
the center, left or right m the L-R "stereo image' For mono operation
PAN assigns the Submaster output to the Left or Right Masters.
PFL (38)
The "in” position oi this switch assigns Sub 1 to PFL.
SUB 1 (39)
This fader sets the level of Submaste' 1
AUX D RETURN SECTION
TO AUX A (40)
Allows the AUX "D" return to be assigned to the AUX "A" mix.
TO AUX B (41)
Allows the AUX "D" return to be assigned to the AUX "B mix.
LEVEL (42)
Controls the level of the AUX D” Return. When an outboard effects
device is patched into the AUX "D" patch loop, the contro determines
the leve of the effect that is routec thru the AUX D Pan control.
PAN (43)
Assigns AUX "D" Return to L & R, or Subs t. 2. 3, and 4. Must be
used n conjunction with assignment switches 41 thru 43.
PFL (44)
The "in" position of this switch assigns the AUX "D" Return to PFL
L-R (45)
The "In" position of this switch routes the AUX "D Return thru
AUX "D” Pan control directly to left, right, or both. The "our position
removes AUX "D' from L and R.
1-2 (46)
The "in" position of this switch routes the AUX ”D' Return thru
AUX "D” Pan control to Sub 1. Sub 2. or both. The "out" position
removes AUX "D" from Subs 1 and 2.
3-4 (47)
The "in" position of this switch routes the AUX "0" Return thru
AUX "D" Pan contro to Sub 3, Sub 4, or both The ’out" position
removes AUX "D" from Subs 3 and 4
Note: Assignment switching works in conjunction with AUX "D" Pan
control 43.
SUB 2 SECTION
PAN (48)
For stereo opera! on. PAN is used to ‘crossfade' the Submaster to the
center, left or rght in the L-P "stereo image.’ For mono operation PAN
assigns the Submaster output to tne Lett or Right Masters.
PFL (49)
The "in" position of this switch assigns Sub 2 to PFL
SUB 2 (50)
This fader sets the level of Submaster 2
AUX E RETURN SECTION
TO AUX A (51)
Allows the AUX "E" return to be assigned to the AUX "A” mix
TO AUX B (52)
Allows line AUX "E" return to be assigned to the AUX ”B' mix.
LEVEL (53)
Controls the level of the AUX "E" Reiurn When an outboard effects
device is patched into the AUX "E" paich loop, ths control delermnes
the level ot the effect that is routed ihru the AUX ’E’ Pan control.
PAN (54)
Assigns AUX * E" Return to L & R, or Sjos 1, 2, 3. and 4. Must be
used in conjunction with assignment switches 56 thru SB.
PFL (55)
The "in" position of this switch assigns the AUX "E" Return to PFL
L-R (56)
The ’ in" position of this switch routes the AUX "E" Return thru
AUX "E" Pan control directly to teft. rght, or both. The "out 1 pcstion
removes AUX "E" from L and R
1-2 (57)
The "in’ oosition of this switch routes the AUX "E" Return thru
AUX "E" Pan control to Sub 1. Sub 2. or both. The "out" position
removes AUX ”E’ from Subs 1 and 2
3-4 (58)
The "in" position of this switch routes the AUX "E" Return thru
AUX "E * Pan control to Sub 3. Sub 4. or both. The out’ oosition
removes AUX "E" from Subs 3 and 4
